    40G 2W 2.92mm Female Connector Wilkinson Power Divider

    Ask Lasest Price
    Brand Name : Vinncom
    Model Number : VN-PD-40G-2.92-2W
    Certification : RoHS/ISO9000
    Price : negotiation
    Payment Terms : T/T, Western Union
    Supply Ability : 50pcs per day
    Delivery Time : 2-4weeks
    • Product Details
    • Company Profile

    40G 2W 2.92mm Female Connector Wilkinson Power Divider

    40G 2W 2 Way Resistive Power Divider 2.92mm Female Connector


    Part NumberVN-PD-40G-2.92-2W
    Operating Frequency ( GHz )DC-40G

    Impedance( Ohm )


    50


    Input VSWR1.50
    Output VSWR≤2.50
    Insertion loss≤7.5
    Average Power (Watt max.)2W

    Isolation(dB)


    ≥9


    Amplitude Balance(dB)


    ±0.5


    Phase Balance±5°

    Operating Temperature( ℃ )


    -35 ~ + 75c


    Interface


    2.92mm Female
    Size17.5*15.8*10mm

    Dimension Tolerance(mm)


    ±0.5

    Mounting


    3-Φ2.2mm through-hole
